FORTRAN is the top leading manufacturer and supplier of automation line in China. Gantry type loading and unloading machine is suitable for calcium silicate board, glass magnesium board, cement fiber board, panel furniture, MDF board and particleboard to move up-down stably. Gantry type loading and unloading machine is suitable for automatic lifting and feeding of large plates, with long durability.

Model:FQ-LMJT2

Send Inquiry

Product Description


1.Product Introduction


Gantry type loading and unloading machine is easy to operate and gantry can be operated with one button. Gantry type loading and unloading machine is simple to operate for saving labor and improving production efficiency. Panel is conveyed to roller table below gantry type loading and unloading machine, then the grab of gantry goes down to panel, sucking and moving the panel to the set position, and finally the grab goes down to the lowest set point and loosens the panel.



2. Product Parameter (Specification)


a. T type two-station bridge loader:


Model FQ-LMJT2
External Dimension L4800*W4800*H4700mm
Panel length 300-2400mm
Panel width 300-1200mm
Loading capacity 50kg/m²
Total power 9KW
Speed 4-5 times/min
Main beam high-strength square steel
Pneumatic component AirTAC
Electric device Schneider
PLC controlling system Delta/ Inovanc
Guide rail Hiwin


b. Two-station bridge loader


Model FQ-LMJT2
External Dimension L4800*W4800*H4700mm
Panel length 300-2400mm
Panel width 300-1200mm
Loading capacity 50kg/m²
Total power 9KW
Speed 4-5 times/min
Main beam high-strength square steel
Pneumatic component AirTAC
Electric device Schneider
PLC controlling system Delta/ Inovanc
Guide rail Hiwin


c. Three-station bridge loader:


Model FQ-LMJ3
External Dimension L5800*W2200*H4700mm
Panel length 300-2400mm
Panel width 300-1200mm
Loading capacity 50kg/m²
Total power 6KW
Speed 4-5 times/min
Main beam high-strength square steel
Pneumatic component AirTAC
Electric device Schneider
PLC controlling system Delta/ Inovance
Guide rail Hiwin


d. Four-station bridge loader:


Model FQ-LMJ4
External Dimension L6800*W2200*H4700mm
Panel length 300-2400mm
Panel width 300-1200mm
Loading capacity 50kg/m²
Total power 6KW
Speed 4-5 times/min
Main beam high-strength square steel
Pneumatic component AirTAC
Electric device Schneider
PLC controlling system Delta/ Inovance
Guide rail Hiwin



3. Product Feature And Application

1.The main beam is made of high-strength square steel. The frame is spliced with the whole square pipe, with high load, to ensure smooth working process and stable structure.
2.The connection part is precisely welded by Japanese OTC robot and formed at one time.
3.Taiwan Delta servo motor, controlling the vacuum cup up or down, with smooth horizontal movement.
4.Gantry type loading and unloading machine adopts high-quality oblique tooth guide rail. Compared with straight tooth guide rail, oblique tooth guide rail has higher wear resistance and stronger lubrication ability.


4.Product Details
